Primitive Pictures

14 Nov 2017


Take an input image like this:

Input for the primitive program.

Create 100 rotated ellipses and store every 5th frame as a Portable Network Graphics (PNG) file:

./primitive -i invplace.png -o rotatedellipse_%03d.png -nth 5 -n 100 -m 7 -v

Animated GIFs

Use those PNG files to create an animated GIF (Graphics Interchange Format):

Using a hundred rotated elipses.

convert -delay 1 -loop 0 rotatedellipse_???.png invplace_rotatedellipse.gif

Or use another mode (e.g. polygon):

Using a hundred polygons.

Use more primitives

Using a thousand rotated elipses.

Using a thousand polygons.

Software used

You can find the source code for the primitive executable (written in Go) on GitHub. There is also a version for macOS. The convert executable is part of ImageMagick.

Have fun with your own images and all the options:

./primitive -h
Usage of ./primitive:
  -a int
    	alpha value (default 128)
  -bg string
    	background color (hex)
  -i string
    	input image path
  -j int
    	number of parallel workers (default uses all cores)
  -m int
    	0=combo 1=triangle 2=rect 3=ellipse 4=circle 5=rotatedrect 6=beziers 7=rotatedellipse 8=polygon (default 1)
  -n value
    	number of primitives
  -nth int
    	save every Nth frame (put "%d" in path) (default 1)
  -o value
    	output image path
  -r int
    	resize large input images to this size (default 256)
  -rep int
    	add N extra shapes per iteration with reduced search
  -s int
    	output image size (default 1024)
  -v	verbose
    	very verbose
